Configurando Link Aggregation na OLT Huawei e Switch Huawei
Configuração da MA5800-X7
enable
config
# 1. Criar o Eth-Trunk com LACP dinâmico/estático (VRP da OLT usa apenas 'lacp')
interface eth-trunk 1
quit
# 2. Adicionar as portas físicas ao Trunk (Entrando no modo da placa de uplink, ex: 0/19)
interface giu 0/19
link-aggregation 0/19/0 0/19/1 eth-trunk 1
quit
# 3. Criar as VLANs na OLT (precisam existir globalmente antes)
vlan 301 smart
vlan 401 smart
vlan 501 smart
# 4. Permitir as VLANs específicas dentro do Eth-Trunk
port vlan 301 0/19 eth-trunk 1
port vlan 401 0/19 eth-trunk 1
port vlan 501 0/19 eth-trunk 1
Configuração do S6730
system-view
# 1. Criar as VLANs primeiro
vlan batch 301 401 501
# 2. Criar o Eth-Trunk
interface Eth-Trunk 1
mode lacp-static
quit
# 3. Adicionar as interfaces físicas
interface 10GE1/0/49
eth-trunk 1
quit
interface 10GE1/0/50
eth-trunk 1
quit
# 4. Configurar o Trunk e passar as VLANs
interface Eth-Trunk 1
port link-type trunk
port trunk allow-pass vlan 301 401 501
quit
Verificação
Na OLT
display eth-trunk 1
display link-aggregation 0/19
display vlan 301
display vlan 401
display vlan 501
No S6730
display eth-trunk 1
Verificar VLANs permitidas
display current-configuration interface eth-trunk 1
